HowTo: Combine Graylog and AlertManager

We like to use the Prometheus AlertManager which handles alerts sent by client applications (e.g. Prometheus, Grafana, ...). It is able to group alerts for you and route them to the correct receiver. The AlertManager allows you to configure your own specified template for sending alert e-mails.

We also like to use Graylog to handle our log-messages and check them for errors or failures. We tried to find an integration for AlertManager in the Graylog-Marketplace but there wasn't one where we could specify our own labels and annotations which we need for our routing and grouping. So we built one on our own and open-sourced it for everyone https://github.com/GDATASoftwareAG/Graylog-Plugin-AlertManager-Callback.

First of all we need to clone and build the GitHub repository of Graylog-AlertManager-Callback plugin.

$ git clone https://github.com/GDATASoftwareAG/Graylog-Plugin-AlertManager-Callback
$ cd Graylog-Plugin-AlertManager-Callback
$ ./gradlew build

This should create a plugin JAR in build/libs/ called graylog-plugin-alertmanagercallback-<version>.jar.

Now we will set up Graylog and our AlertManager by using the following configuration and Docker-Compose files:

# If you are running more than one instances of Graylog server you have to select one of these
# instances as master. The master will perform some periodical tasks that non-masters won't perform.
is_master = true

# The auto-generated node ID will be stored in this file and read after restarts. It is a good idea
# to use an absolute file path here if you are starting Graylog server from init scripts or similar.
node_id_file = /usr/share/graylog/data/config/node-id

# You MUST set a secret to secure/pepper the stored user passwords here. Use at least 64 characters.
# Generate one by using for example: pwgen -N 1 -s 96
password_secret = somepasswordpepper

# The default root user is named 'admin'
#root_username = admin

# You MUST specify a hash password for the root user (which you only need to initially set up the
# system and in case you lose connectivity to your authentication backend)
# This password cannot be changed using the API or via the web interface. If you need to change it,
# modify it in this file.
# Create one by using for example: echo -n yourpassword | shasum -a 256
# and put the resulting hash value into the following line
root_password_sha2 = 8c6976e5b5410415bde908bd4dee15dfb167a9c873fc4bb8a81f6f2ab448a918

# Set plugin directory here (relative or absolute)
plugin_dir = /usr/share/graylog/plugin

# REST API listen URI. Must be reachable by other Graylog server nodes if you run a cluster.
# When using Graylog Collectors, this URI will be used to receive heartbeat messages and must be accessible for all collectors.
rest_listen_uri = http://0.0.0.0/api/

# Web interface listen URI
web_listen_uri = http://0.0.0.0:9000/

# MongoDB connection string
# See https://docs.mongodb.org/manual/reference/connection-string/ for details
mongodb_uri = mongodb://mongo/graylog

version: '2'
services:
  mongo:
    image: mongo:3

  graylog:
    image: graylog/graylog:2.5.0-1
    volumes:
      # Add the modified graylog.conf
      - ./graylog.conf:/usr/share/graylog/data/config/graylog.conf
      # Add the Graylog AlertManager-Callback plugin
      - ./graylog-plugin-alertmanagercallback-1.0.jar:/usr/share/graylog/plugin/graylog-plugin-alertmanagercallback-1.0.jar
    ports:
      # Graylog web interface and REST API
      - 9000:9000

  alertmanager:
    image: prom/alertmanager:v0.16.1
    ports:
      - 9093:9093

As you can see we map our generated plugin JAR into our Graylog container. Graylog uses the /usr/share/graylog/plugin/ directory (which is defined in the graylog.conf) to read the plugins from.
Now we need to start the compose by using:

$ docker-compose up
